D-Link 16-port UTP Gigabit, 2-port Gigabit SFP (DGS-1100-18)

• 12 x 10/100/1000Base-T Ports
• 12 x 10/100/1000Base-T PoE Ports
• 100W PoE Power Budget
• Fanless design for silent operation
• Bandwidth Control ensures latency-sensitive traffic always gets the bandwidth it needs
• Quality of Service further prioritizes latency-sensitive traffic, ensuring timely delivery
• Segregate different types of traffic, such as surveillance or voice, with VLANs to heighten security
• IGMP Snooping sends multicast traffic only where it needs to go, significantly cutting down network traffic
• Innovative energy saving features are good for your budget, as well as the environment
• Get up and going quickly with streamlined first-time setup and ongoing management

Specifications

• Auto MDI/MDIX: Yes
• 10/100/1000BASE-T PoE ports: 12
• 10/100/1000BASE-T port :12
• Port-based Bandwidth Control:Yes
• Class of Service (CoS) :Yes
• 802.3x Flow Control :Yes
• Store-and-Forwarding :Yes
• Comply with RoHS 6 :Yes
• Energy Efficiency Ethernet (EEE) :Yes
• FAN : Fanless
• Jumbo Frame: 9216 bytes
• Loopback Detection (LBD) :Yes
• IGMP Snooping :Yes
• 802.1AX Link Aggregation :Yes
• 802.3ad Link Aggregation :Yes
• SNMP :Yes
• Web-based GUI :Yes
• D-Link Discover Protocol (DDP) :Yes (v0.25)
• D-Link Network Assistant :Yes
• Port Mirroring :Yes
• Cable Diagnostics :Yes
• Switch Capacity :48 Gbps
• Max. Packet Forwarding Rate : 35.71 Mpps
• Maximum PoE Budget : 100W
• PoE Budget : 100 W (30 W max. per PoE port)
• Rate Limiting :Yes
• Power Input AC: 100-240V
• Queue Handling :Yes
• Strict Priority Queue (SPQ) :Yes
• Weighted Round Robin (WRR) :Yes
• SSL :Yes
• Broadcast/Multicast/Unicast Storm Control :Yes
• Traffic Segmentation :Yes
• D-Link Safeguard Engine :Yes
• DoS Attack Prevention :Yes
• 802.1D Spanning Tree (STP) :Yes
• 802.1w Rapid Spanning Tree (RSTP) :Yes
• Dimension :280x 230x 44mm
• Weight :2.20 Kg
• Operation Temperature :-5-50?C
• 802.1Q VLAN :Yes
• Port-based VLAN :Yes
• Voice VLAN :Yes
• Auto Surveillance VLAN :Yes
• Asymmetric VLAN :Yes
