Intel NUC Kit (BOXNUC7PJYHN1)

Intel NUC7 Pentium J5005 4C 1.50 - 2.80GHz 4M, UHD Graphic 605, 2xHDMI2.0a, Lan + Wi-Fi. No codec, no OS, 3Y

Specs

• Product Collection: Intel NUC Kit with Intel Pentium Processors
• Code Name: Products formerly JUNE CANYON
• Supported Operating Systems: Windows 10, 64-bit*
• Board Number: NUC7JYBN
• Board Form Factor: UCFF (4" x 4")
• Socket: Soldered-down BGA
• Internal Drive Form Factor: 2.5" Drive
• # of Internal Drives Supported: 1
• Lithography: 14 nm
• TDP: 10 W
• DC Input Voltage Supported: 12-19 VDC
• Processor Included: Intel Pentium Silver J5005 Processor (4M Cache, up to 2.80 GHz)
• Intel vPro Platform Eligibility : No
• # of Cores: 4
• # of Threads: 4
• Processor Base Frequency: 1.50 GHz

Memory & Storage

• Max Memory Size (dependent on memory type): 8 GB
• Memory Types: DDR4-2400 1.2V SO-DIMM
• Max # of Memory Channels: 3
• Max Memory Bandwidth: 38.4 GB/s
• Max # of DIMMs: 2
• ECC Memory Supported : No

Processor Graphics

• Integrated Graphics: Yes
• Graphics Output: 2x HDMI 2.0a
• # of Displays Supported : 2

Expansion Options

• Removable Memory Card Slot: SDXC with UHS-I support

I/O Specifications

• # of USB Ports: 6
• USB Configuration: 2x front and 2x rear USB 3.0; 2x USB 2.0 via internal headers
• USB Revision: 2.0, 3.0
• USB 2.0 Configuration (External + Internal): 0 + 2
• USB 3.0 Configuration (External + Internal): 2B 2F + 0
• Total # of SATA Ports: 1
• Max # of SATA 6.0 Gb/s Ports: 1
• Audio (back channel + front channel): 7.1 digital
• Integrated LAN: Realtek 8111H-CG
• Integrated Wireless: Intel Wireless-AC 9462 + Bluetooth 5.0
• Integrated Bluetooth: Yes
• Consumer Infrared Rx Sensor: Yes
• Additional Headers: CEC, 2x USB2.0, AUX_PWR, FRONT_PANEL

Package Specifications

• Chassis Dimensions: 115 x 111 x 51mm

Advanced Technologies

• Intel Virtualization Technology for Directed I/O (VT-d): Yes
• Intel vPro Platform Eligibility: No
• TPM: No
• Intel Platform Trust Technology (Intel? PTT): Yes

Security & Reliability

• Intel AES New Instructions: Yes
