- Height: 10.63 in (270 mm)
- Width: 10.24 in (260 mm)
- Depth: 10.94 in (278 mm)
- Weight without cables: 4.96 lbs (2.25 kg)
PEDALS PHYSICAL SPECIFICATIONS
- Height: 6.57 in (167 mm)
- Width: 16.87 in (428.5 mm)
- Depth: 12.24 in (311 mm)
- Weight without cables: 6.83 lbs (3.1 kg)
WHEEL TECHNICAL SPECIFICATIONS
- Rotation: 900 degrees lock-to-lock
- Hall-effect steering sensor
- Dual-Motor Force Feedback with TRUEFORCE
- Overheat safeguard
PEDAL TECHNICAL SPECIFICATIONS
- Nonlinear brake pedal
- Patented carpet grip system
- Textured heel grip
- Self-calibrating
MATERIALS
- Wheel spokes: Anodized aluminum
- Wheel cover Hand-stitched leather
- Steering shaft: Steel
- Shifter paddles: Brushed stainless steel
- Mounting clamps: Glass-filled nylon
- Pedal frames and arms: cold rolled steel
- Pedal piston sleeves: Polyoxymethylene thermoplastic (POM)
WARRANTY INFORMATION
- 2-Year Limited Hardware Warranty
PART NUMBER
- Black Xbox Series X|S /Xbox One/PC: 941-000156
- Black PS5 /PlayStation /PC: 941-000147
SYSTEM REQUIREMENTS
- REQUIREMENTS (XBOX SERIES X|S AND XBOX ONE)
- Xbox Series X|S or Xbox One game system
- Game that supports Logitech force feedback racing wheel 1For a list of supported games, visit logitechg.com/support/g923-xb1
REQUIREMENTS (PLAYSTATION 5 OR PLAYSTATION 4)
- PlayStation 5 or PlayStation 4 system
- Game that supports Logitech force feedback racing wheel. 2For a list of supported games, visit logitechg.com/support/g923-xb1
REQUIREMENTS (PC)
- Windows? 11 or Windows 10
- 150 MB of available hard disk space
- USB 2.0 port
- Game that supports Logitech force feedback racing wheel. 3For a list of supported games, visit logitechg.com/support/g923-xb1
IN THE BOX
- Steering wheel
- Pedals
- Power supply
- User documentation
